Block
Insect-free sun protection
Insect-free sun protection
The Block-range is Copaco’s solution for those who want to keep out sunlight or insects completely. But in the meanwhile want to maintain the ambiance of their space. Ae you going for a sober or flashy? Translucent or opaque? Strike a perfect balance between comfortable, stylish, private or insect-free by choosing from the Block collection’s wide and innovative range.
Opac 400 Classic - white




openness
factor
0%
product_front
Front
product_back
Back
Innovations
Reflect sunlight
Openness factor 0%
Widths
Product ref.
200 cm
300 cm
002002 - white


  •
    Available
Technical info
General


Composition
Fabric of vinyl laminated glassfibre
Openness factor
NBN EN 410
0.00%
Weight
NF EN 12127
432.00 g/m²
Thickness
ISO 5084
0.34 mm
Color fastness to artificial light
ISO 105 B02
7
Roll length
30 m
Cleaning
With soapy water
Confection
By heat, high frequency or ultrasonic welding
Fire classification

Europe
UNE-EN 13501-1:2007
C-s3, d0
France
NF P92-503
M1
Italy
UNI 9177
Class 1
Germany
DIN 4102
B1
UK
BS 5867
C
USA
NFPA 701
FR
Tear strength
ISO 4674-1 method 2


Original
Warp6.90 daN
Weft6.30 daN
After climatic chamber -30°C
Warp5.60 daN
Weft5.30 daN
After climatic chamber +70°C
Warp6.70 daN
Weft5.30 daN
Elongation up to break
ISO 1421


Original
Warp3.90 %
Weft3.74 %
After color fastness to artificial light
Warp3.17 %
Weft3.26 %
After climatic chamber -30°C
Warp3.48 %
Weft4.24 %
After climatic chamber +70°C
Warp4.32 %
Weft4.16 %
Breaking strength
ISO 1421


Original
Warp168.60 daN/5cm
Weft201.30 daN/5cm
After color fastness to artificial light
Warp94.10 daN/5cm
Weft105.50 daN/5cm
After climatic chamber -30°C
Warp151.70 daN/5cm
Weft221.10 daN/5cm
After climatic chamber +70°C
Warp182.80 daN/5cm
Weft223.90 daN/5cm
Front - Interior


Visual properties
Tv = Visual light transmittance
0.00%
Tuv = UV transmittance
0.00%
Solar energetic properties
As = Solar absorptance
24.50%
Rs = Solar reflectance
75.30%
Ts = Solar transmittance
0.20%
Fabric + glazing: G-factor

G
Te
Qi
SC
Glazing A
G 0.27
Te 0.00
Qi 0.27
SC 0.32
Glazing B
G 0.31
Te 0.00
Qi 0.31
SC 0.41
Glazing C
G 0.32
Te 0.00
Qi 0.32
SC 0.55
Glazing D
G 0.24
Te 0.00
Qi 0.24
SC 0.75
  • G = Total solar energy transmittance
  • Te = Direct solar transmittance
  • Qi = Secondary heat transfer factor
  • SC = Shading coefficient
Visual comfort
Normal solar transmittance
Class 4
Very good effect
Glare control
Class 4
Very good effect
Privacy night
Class 2
Moderate effect
Visual contact with the outside
Class 2
Moderate effect
Daylight utilisation
Class 0
Very little effect
Thermal comfort G-factor = Total solar energy transmittance
Glazing A
Class 2
Moderate effect
Glazing B
Class 2
Moderate effect
Glazing C
Class 2
Moderate effect
Glazing D
Class 2
Moderate effect
Thermal comfort Qi-factor = Secondary heat transfer factor
Glazing A
Class 1
Little effect
Glazing B
Class 0
Very little effect
Glazing C
Class 0
Very little effect
Glazing D
Class 1
Little effect
  • Class 0 = Very little effect
  • Class 1 = Little effect
  • Class 2 = Moderate effect
  • Class 3 = Good effect
  • Class 4 = Very good effect
Back - Interior


Visual properties
Tv = Visual light transmittance
0.00%
Tuv = UV transmittance
0.00%
Solar energetic properties
As = Solar absorptance
21.70%
Rs = Solar reflectance
78.10%
Ts = Solar transmittance
0.20%
Fabric + glazing: G-factor

G
Te
Qi
SC
Glazing A
G 0.26
Te 0.00
Qi 0.25
SC 0.30
Glazing B
G 0.29
Te 0.00
Qi 0.29
SC 0.39
Glazing C
G 0.31
Te 0.00
Qi 0.31
SC 0.53
Glazing D
G 0.24
Te 0.00
Qi 0.24
SC 0.74
  • G = Total solar energy transmittance
  • Te = Direct solar transmittance
  • Qi = Secondary heat transfer factor
  • SC = Shading coefficient
Visual comfort
Normal solar transmittance
Class 4
Very good effect
Glare control
Class 4
Very good effect
Privacy night
Class 2
Moderate effect
Visual contact with the outside
Class 2
Moderate effect
Daylight utilisation
Class 0
Very little effect
Thermal comfort G-factor = Total solar energy transmittance
Glazing A
Class 2
Moderate effect
Glazing B
Class 2
Moderate effect
Glazing C
Class 2
Moderate effect
Glazing D
Class 2
Moderate effect
Thermal comfort Qi-factor = Secondary heat transfer factor
Glazing A
Class 1
Little effect
Glazing B
Class 1
Little effect
Glazing C
Class 0
Very little effect
Glazing D
Class 1
Little effect
  • Class 0 = Very little effect
  • Class 1 = Little effect
  • Class 2 = Moderate effect
  • Class 3 = Good effect
  • Class 4 = Very good effect
Indoor comfortEasy maintenanceEnergy savingFlame retardant
